Product Description
AVAILABLE FOR SALE IS A SQUARE D HU-361 30A 30HP 600V AC/DC HEAVY DUTY SAFETY SWITCH. THIS PRODUCT IS NEW IN AN OPEN BOX. THE BOX HAS BEEN OPENED. SOME OF THE BOX CONTENTS MIGHT HAVE BEEN REMOVED, AND EVERYTHING THAT WOULD'VE BEEN INCLUDED MAY OR MAY NOT BE INCLUDED. PLEASE REVIEW THE PHOTOS TO DETERMINE IF ANY COMPONENTS ARE MISSING OR ASK QUESTIONS PRIOR TO PURCHASE.Manufacturer: Schneider Electric
Manufacturer Part Number (MPN): HU361
Model: HU361
Number of Poles: 3
Current Type: AC/DC
Voltage: 600VAC/DC
Amperage: 30A
Enclosure: NEMA 1 steel
Switch Type: Non-Fusible
Switch Style: Decorator/Rocker
Operation Method: Switch with handle
Horsepower Rating
5hp at 240V AC 50-60Hz for 1-phase motors
10hp at 240V AC 50-60Hz for 3-phase motors
7.5hp at 480V AC 50-60Hz for 1-phase motors
20hp at 480V AC 50-60Hz for 3-phase motors
10hp at 600V AC 50-60Hz for 1-phase motors
30hp at 600V AC 50-60Hz for 3-phase motors
5hp at 250V DC
15hp at 600V DC Mounting Type: Surface Application: Heavy Duty Industrial Electrical Connection: Lugs Wiring Configuration: 3-wire Wire Size:
AWG 12...AWG 6 aluminum
AWG 14...AWG 6 copper Tightening Torque:
45 lbf.in (5.08 N.m) 0.02 in2 (13.3 mm2) (AWG 6)
40 lbf.in (4.5 N.m) 0.013 in2 (8.367 mm2) (AWG 8)
35 lbf.in (4.0 N.m) 0.003...0.008 in2 (2.06...5.261 mm2) (AWG 14...AWG 10) Depth: 4.87 in (123.70 mm) Width: 7.55 in (191.77 mm) Height: 14.6 in (370.8 mm) Net Weight: 8.8 lb(US) (4 kg) Certifications: UL listed file E2875
Disclaimer: Always verify these specifications and any certifications with the manufacturer or an authorized distributor, especially for critical applications.
