Product Description
The Jelight 78PA-2046-2 is a professional-grade, cold cathode mercury vapor lamp engineered for high-precision scientific and industrial UV applications. Utilizing Jelight’s proprietary Double-Bore® design, this lamp features a quartz septum through the center that allows plasma to travel in a continuous arc, providing unmatched stability and uniformity. Because this "78" series model is constructed from Synthetic Silica, it is an ozone-producing light source, transmitting the critical 185 nm line required for organic carbon oxidation and ozone generation.
Condition Detail: New - Open Box. This item is in new, unused condition. The original protective packaging has been opened to confirm technical specifications and for photography.
Critical Equipment Compatibility: This lamp is a high-demand replacement component for precision laboratory instrumentation, including: TOC Analyzers: Replacement for Anatel PAT700, Anatel A-643a, and Sievers/Suez M9, 500RL, and 900 series. Analytical Instruments: HPLC Detectors, Spectrophotometers, and Spectrometers. Industrial Units: Jelight Model 12/256 UVO Cleaners and Ozone Generators.
Brand JELIGHT
MPN 78PA-2046-2
Model 78-2046-2
Type Low-pressure mercury vapor UV lamp
Lighting Technology Double-Bore® Calibration Lamp
Compatible Brands Anatel, Sievers, Suez, Hach, Suez
Material Synthetic Silica (Ozone-Producing)
Emission Spectrum 185 nm and 254 nm
Intensity 6.0 mW/cm² (at 3/4" distance)
Operating Voltage 270 V
Starting Voltage 800 V
Overall Length (B) 2.125 in (5.4 cm)
Lamp Diameter (A) 6.5 mm
Country of Origin United States
Technical Specifications Summary:
Intensity: 6.0 mW/cm²
Operating Voltage: 270V
Starting Voltage: 800V
Emission Wavelengths: 185 nm (Ozone) and 254 nm (Primary)
Lamp Life: Typically rated for 5,000 to 30,000 hours
Construction: Double-bore quartz tube with integrated leads at one end
Safety Information:
Ozone Generation: This lamp is made of synthetic silica and will generate ozone during operation. Ensure proper ventilation for your application.
UV Warning: Emits high-intensity UV radiation. Always use appropriate eye and skin shielding to protect from direct exposure.
APPLICATIONS
HPLC
TOC Analyzer
Calibration of Photometers
Mercury Analyzer
Photochemistry
Atomic Absorption
Spectrometry
Ozone Monitor
Ozone Generator
Immunoassays
Calibrations of Spectroscopes
Medical Instruments
Flouromicroscopy
Pollution Instrumentations
Spectrophotometry
Interferometry
Flourescence
UV Curing and Drying
And More…
