Product Description
AVAILABLE FOR SALE IS A CISCO IR809G-LTE-VZ-K9 VERIZON 809 INDUSTRIAL INTEGRATED SERVICES ROUTER. THIS PRODUCT IS SEALED IN THE ORIGINAL PACKAGING. PRODUCT MIGHT NOT BE IN RETAIL CONDITION, AND THE BOX MIGHT HAVE BEEN DAMAGED DUE TO STORAGE AND HANDLING.MAKE: CISCO
MODEL: IR809G-LTE-VZ-K9
Product Identification
Product Name: Cisco 809 Industrial ISR, 4G/LTE Multimode Verizon
Product Type: Ruggedized Wireless Integrated Services Router (ISR) designed for industrial environments.
Carrier: Verizon Wireless (US)
Generation: 4G LTE
Supported LTE Bands:
Band 13 (700 MHz)
Band 4 AWS (1700/2100 MHz)
Band 25 extended PCS (1900 MHz)
Backward Compatibility: EVDO Rev A / CDMA 1x (BC0, BC1, BC10)
Theoretical Speeds: Up to 100 Mbps downlink, 50 Mbps uplink (Actual speeds depend on network conditions)
Modem: Embedded Sierra Wireless MC7350 with Qualcomm MDM9615 (PCI minicard form factor)
SIM Slots: Dual Mini-SIM slots (2FF form factor), compliant with ISO-7816-2. Supports dual SIM for reliability and failover.
GPS: Integrated standalone GPS (requires line of sight). Features an SMA connector for an optional external active GPS antenna.
SMS: Supports sending and receiving SMS messages (up to 160 characters).
Interfaces
LAN/WAN Ports: 2 x 10/100/1000 Base-T Gigabit Ethernet (RJ-45) ports
Console Port: 1 x Mini Type-B USB for console access and remote diagnostics/monitoring.
USB Port: 1 x USB 2.0 (Type A) port
Serial Ports: 2 x Serial Ports supporting RS-232 and RS-232/485 for SCADA communications.
Memory
DRAM: 2 GB (Default and maximum)
Flash Memory: 8 GB eMMC (4 GB usable for storage)
Software and Features
Operating System: Cisco IOS
VPN Support: Yes (Includes IPsec, SSL VPN, Dynamic Multipoint VPN - DMVPN, Flexible VPN - FlexVPN)
Security: Integrated Firewall, Access Control Lists (ACLs), Secure Boot, Image Signing, Authentication (RADIUS, TACACS+)
Management: SNMP, Telnet, SSH, HTTP/HTTPS, Cisco IoT Field Network Director
Industrial Protocols: SCADA support (DNP3, T101-104), Raw Socket TCP/UDP, SLIP
Other Key Features: Quality of Service (QoS), Multi-VRF, Cisco IOx (open, extensible application environment), Accelerometer/Gyroscope (for potential motion/tamper detection).
Power Specifications
Input Voltage: 9.6 to 60 VDC
Power Consumption:
Idle: ~12W
Typical: ~15W
Maximum: ~19W (Some sources mention up to 29W max platform consumption)
Current Draw: Max 2A @ 9.6VDC, Min 0.4A @ 60VDC
Other Details
Before requesting a return, please contact us, as we can often times troubleshoot problems through email. All returns must include all original items in the same condition they were sent. We will also issue an RMA number which must be present on the exterior of the returned box. Your return will not be processed without your RMA number on the box. The buyer is responsible for all return shipping charges.We are not responsible for any technical specifications, compatibility, fitment, application issues, buyer’s remorse, or if an item was purchased by mistake. Any return or refund requested for these reasons will be charged a 20% restocking fee.
We offer the following return guidelines for the products we have available:
New other – All of our new product falls into this category since manufacturer packaging has usually been opened or is otherwise not in retail condition. We offer a full refund of the purchase price less shipping charges for “New other” products that are not in working condition for up to 30 days after receipt.
Seller refurbished – Our refurbished items have been tested and verified by our in-house staff and we guarantee the tested components for 30 days after receipt. We will refund the purchase price less shipping charges for “Seller refurbished” products that are not in working condition when received.
Used – All used products carry a 30 day non-DOA warranty. These products may not be 100% functional and only basic power on capabilities are guaranteed. If a “used” product is received and will not power on, we will issue a full refund less shipping charges. Partial refunds will not be issued for non-working components, and a 20% restocking fee will be charged to all returns of product that do power on.
For parts or not working – There are no warranties or return options available for merchandise that is listed as “for parts or not working”. All returns will be processed with a 20% restocking fee.
